    //Woodworking Machinery

    Planer Sander

    Wood processing machine incorporating planer and wide belt sander in a single machine
    • Working width20-1300mm
    • Max. transverse angle30°
    • Planner motor power22kW
    • Feeding motor power4kW

    The planer sander integrates planing and sanding operations into a single machine, designed to efficiently process wood panels with uneven thickness while refining the surface to a smooth, clean finish. It removes cutter marks left from previous processing steps and delivers a high-quality surface ready for coating or assembly. This all-in-one solution improves production efficiency and surface quality in wood furniture and panel manufacturing.

    Request a Quote
    Specifications
    • Working width 20-1300mm
    • Working thickness 4-150mm
    • Working length (per timber) >580mm
    • Sanding belt size (L×W) 2200×1300mm
    • Max. transverse angle 30°
    • Planner motor power 22kW
    • First sanding belt motor power 30kW
    • Second sanding belt motor power 22kW
    • Feeding motor power 4kW
    • Up and down motor power 0.37kW
    • Brush motor power 0.37kW
    • Feeding speed 0-19m/min
    Features
    • Helical cutterhead
      The spiral blade arrangement enables sequential, angled cutting, reducing cutting force and extending tool life.
    • Multi-layer safety protection
      Includes one-way feed rollers, segmented pressure controls, and a heavy-duty anti-kickback device to ensure operator safety.
    • High adjustability
      Variable frequency feed control and adjustable sanding head height and depth provide flexibility to accommodate different processing requirements.
