Chair Legs Height Leveling Cut-Saw
Wood furniture production machine for cutting chair legs to the same length
Woodworking Machinery
//Woodworking Machinery
Chair Legs Height Leveling Cut-Saw
Wood furniture production machine for cutting chair legs to the same length
This woodworking machine is widely used to cut wooden chair legs to consistent lengths, ensuring all four legs are level and stable after assembly. It improves the overall precision and finish rate of completed chairs, minimizing the need for post--assembly adjustments. The cut-saw is simple to operate and ideal for furniture production lines focused on accuracy and high-quality output.
Specifications
- Machine dimensions 1230×900×420mm
- Cutting saw diameter 300mm, tooth number 120 teeth, thickness 3.6 mm
- Air pressure 0.6/0.8kPa
- Work table size (W×L×H) 800×900×100mm
- Voltage 380V
- Working mode semi-automatic cutting
- Weight 150kg
- Dust suction inlet diameter 90mm
- Temperature adjustment range 35℃ to 90℃
- Motor power 1100W
- Switch CHNT switch
